Ground and Terminal Block Locations for CE Gas and Steam Models
TMB2247N_SVG
2
1
3
4
5
1. Earth/Ground
2. Junction Box
3. Terminal Block
4. Power Disconnect (Models Through 7/31/11)
5. Electrical Service
Figure 18
Electrical Requirements
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
53 Part No. 70458101ENR10
