Non-CE Models
TMB2270N_SVG
2
1
CE Models
TMB2271N_SVG
2
1
3
1. Ferrite Ring
2. Junction Box
3. Models Through 7/31/11
Figure 20
Electrical Requirements
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
56 Part No. 70458101ENR10
