Alliance Laundry Systems CA170L - Page 58

170 Series Tumble Dryer Models
Serial Plate Rat-
ing
Terminal Block
Connections Re-
quired
Rated Current*
(amps) Breaker Rating
Recommended
Wire Size AWG
[mm²]
200-208/240V/
60Hz/3ph
L1,L2,L3 and ground 13.5 20A - 3 pole 12 [4]
380V/50 or 60Hz/3ph L1,L2,L3 and ground 6.9 15A - 3 pole 14 [2.5]
400-415V/50Hz/3ph L1,L2,L3 and ground 6.9 15A - 3 pole 14 [2.5]
440V/60Hz/3ph L1,L2,L3 and ground 6.4 15A - 3 pole 14 [2.5]
460-480V/60Hz/3ph L1,L2,L3 and ground 6.7 15A - 3 pole 14 [2.5]
* Current ratings vary slightly depending on model; refer to serial plate.
200 Series Tumble Dryer Models
Serial Plate Rat-
ing
Terminal Block
Connections Re-
quired
Rated Current*
(amps) Breaker Rating
Recommended
Wire Size AWG
[mm²]
200-208/240V/
60Hz/3ph
L1, L2, L3 and ground 14 20A - 3 pole 12 [ 4]
380V/50Hz/3ph L1, L2, L3 and ground 8 15A - 3 pole 14 [2.5]
400-415V/50Hz/3ph L1, L2, L3 and ground 8 15A - 3 pole 14 [2.5]
440V/60Hz/3ph L1, L2, L3 and ground 7 15A - 3 pole 14 [2.5]
460-480V/60Hz/3ph L1, L2, L3 and ground 7 15A - 3 pole 14 [2.5]
* Current ratings vary slightly depending on model; refer to serial plate.
Electrical Requirements
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
58 Part No. 70458101ENR10
