NOTE: Using a Belt Tension Gauge, the motor belt
deflection should be 0.31 inch at five pounds pres-
sure, and final drive belt deflection should be 0.25
inch at five pounds pressure.
Belts should not slip or make any noise when starting up under
normal load.
Drive Motor
Final Drive Blower
Initial
After Run-
in Initial
After Run-
in Initial
After Run-
in
120 60-70 45-55 70-80 55-65 60-70 50-55
170 60-70 45-55 70-80 55-65 75-80 60-65
200 60-70 45-55 70-80 55-65 65-70 55-60
Table 13
Adjustments
©
