46 M413438
Section 5 Service Procedures
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 19
White Rodgers
Instant Electronic Ignition System (IEI)
REDUNDANT
COIL
REDUNDANT
COIL
GAS
VALVE
BODY
GAS
VALVE
BODY
MAIN
COIL
MAIN
COIL
T002SE3A
White Rodgers Glow-Bar
GAS VALVE
BODY
MAGNETIC
OPERATORS
Automatic Pilot System
Johnson Controls Glow-Bar
GAS VALVE
BODY
PILOT
OPERATOR
MAIN
OPERATOR
Standing Pilot
GAS
VALVE
BODY
RESET
ASSEMBLY
OPERATOR
