AT-9000 Switch Command Line User’s Guide
1199
Creating ACLs
This section provides examples of how to create all of the ACL types. See
the following:
 “Creating Numbered IPv4 ACLs” on page 1199
 “Creating Numbered MAC ACLs” on page 1211
For descriptions of the commands mentioned in these procedures, refer to
Chapter 74, “ACL Commands” on page 1229.
Creating
Numbered IPv4
ACLs
Depending on the type of filter that you want to create, there are five
commands for creating Numbered IPv4 ACLs. These commands are listed
in Table 121. All of the commands for creating Numbered IPv4 ACLs begin
with “ACCESS-LIST” and are found in the Global Configuration mode.
For examples of the commands listed in Table 121, see the following:
 “Numbered IPv4 ACL with IP Packets Examples” on page 1200
 “Numbered IPv4 ACL with ICMP Packets Example” on page 1204
 “Numbered IPv4 ACL with Protocol Packets Example” on page 1206
 “Numbered IPv4 ACL with TCP Port Packets Example” on page 1207
 “Numbered IPv4 ACL with UDP Port Packets Example” on page 1209
Table 121. ACCESS-LIST Commands for Creating Numbered IPv4 ACLs
To Do This Task Use This Command
Create Numbered IPv4 ACLs for
source and destination IPv4
addresses.
ACCESS-LIST
id_number action IP
src_ipaddress dst_ipaddress [VLAN vid]
Create Numbered IPv4 ACLs for
ICMP packets.
ACCESS-LIST id_number action ICMP
src_ipaddress dst_ipaddress
[VLAN vid ]
Create Numbered IPv4 ACLs for
packets of specified protocols.
ACCESS-LIST
id_number action PROTO
protocol_number src_ipaddress
dst_ipaddress
[vlan vid ]
Create Numbered IPv4 ACLs that filter
ingress packets based on TCP port
numbers.
ACCESS-LIST
id_number action TCP
src_ipaddress EQ|LT|GT|NE|RANGE
src_tcp_port dst_ipaddress
EQ|LT|GT|NE|RANGE dst_tcp_port [VLAN vid ]
Create Numbered IPv4 ACLs that filter
ingress packets based on UDP port
numbers.
ACCESS-LIST
id_number action UDP
src_ipaddress EQ|LT|GT|NE|RANGE
src_udp_port dst_ipaddress
EQ|LT|GT|NE|RANGE dst_udp_port [VLAN vid ]

Allied Telesis AT-9000/28SP Specifications

General

Number of Ports	28
Port Type	Gigabit Ethernet
Ports	24 x 10/100/1000Base-T, 4 x SFP
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Power over Ethernet (PoE)	No
Rack Mountable	Yes
Product Type	Switch
Layer	3
MAC Address Table Size	16K
VLANs	4K
Jumbo Frames	9K
Dimensions (W x D x H)	440 x 240 x 44 mm
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
