4.0 Operation, continued
4.3 Smart Display modes for XM2-300HP
4.3.1 Operation Normal
Fig. 4-4, Operation Normal Display
OPERATION NORMAL
OPER MODE = LINE
BATT STATUS OK
INV STATUS OK
DPM STATUS OK
INPUT VOLTAGE 120
INPUT FREQ 60HZ
INPUT CURRENT 23.0A
INPUT WATTS 140
OUTPUT VOLTAGE 60
OUTPUT 1 CURR 1.0A
OUTPUT 2 CURR 1.0A
OUTPUT CURRENT 2.0A
OUTPUT WATTS 120 W
OUTPUT VA 120 VA
PERCENT LOAD 33%
CHARGER MODE = ACCEPT
BATT VOLTAGE 14.4V
BATTERY TEMP 26.5C
ENCLOSURE TEMP 26.5C
CHARGER CURR 5.0A
EST. BATT RUN < 60 MIN
1 EVENTS 84 MIN
Top line
Second line
The top line indicates the current screen and provides additional instructions. Use the
The second line cycles through the parameters listed above.
*
Only visible in single-step mode
*
*
*
37
017-877-B1-001 Rev. A
