Fig. 4-6, Setup Menu Display
4.0 Operation, continued
4.3 Smart Display modes for XM2-300HP, continued
4.3.3 Setup Menu, continued
SETUP MENU
CODE VER 7.01.0
DEVICE ADDRESS 1
ALPHACELL OTHER
FLOAT V/C 2.27
ACCEPT V/C 2.40
TEMP COMP 5mV
BATT CAPACITY 100Ah
# BATT STRINGS* 1
BATT 1 DATE M/Y* 01/10
BATT 2 DATE M/Y** 01/10
BATT 1 MHOS* 1050
BATT 2 MHOS** 1050
MHO 1 DATE M/Y* 01/10
MHO 2 DATE M/Y** 01/10
BATTERY 1 LIFE* 5Y
BATTERY 1 AGE* 5Y
BATTERY 2 LIFE** 0 MO
BATTERY 2 AGE** 0 MO
MHOS MIN LEVEL* 80%
MHOS MAJ LVL* 60%
STANDBY TIME 65 M
STANDBY EVENTS 12
TOTAL RUN TIME 365D
SELF TEST OFF
TEST INTERVAL 30D
TEST INHIBIT —
% DISCHARGE 00%
TEST DURATION 10 M
TEST COUNTDOWN 30D
FREQ RANGE 3.0HZ
PIM OPTION YES
RESET OUTPUT 1 —
RESET OUTPUT 2 —
OVER CURR 1 15.0A
OVER CURR 2 15.0A
RETRY DELAY 60S
RETRY LIMIT 20
OVER CURR TOL 3000ms
SYSTEM FAN NO
HEATER MAT NO
PS PRIORITY NORMAL
TECHNICIAN ID 123
INPUT LIMIT 6.0
SET DEFAULTS NO
SELECT LANGUAGE ENGLISH
41
017-877-B1-001 Rev. A
