Charger Accept Voltage: Battery Accept charge voltage control in volts per cell. This voltage,
properly completes the charge cycle and is factory set for AlphaCell batteries. If another
Charger Float Voltage: Battery Float charge voltage control in volts per cell. The average is
Charger Temperature Compensation: Battery charger temperature compensation control.
manufacturer for Charger Temperature compensation ranges.
Date of Last Conductance (MHO’s) Reading:
performed on the battery.
End of Battery Discharge (EOD):
batteries.
Frequency Range Limit
Output 1 Overcurrent Trip level: Primary leg:
Output 2 Overcurrent Trip level: Secondary leg:
optional PIM is installed.
Major Conductance Alarm:
critical level. This is an indication the battery is near the end of its useful life.
Minor Conductance Alarm:
observation.
4.0 Operation, continued
4.6 Smart Display Glossary
Battery Capacity: The capacity of the battery strings attached to a particular XM2-300HP.
operations, including test mode, and disables the No Batteries Alarm. If batteries are attached,
then this setting should be programmed to the total rating of all the battery strings.
Battery Conductance (MHO’s) Reading: The battery conductance is measured in Siemens
resistance of the battery and is useful in evaluating and maintaining the battery.
Battery Date Code:
of the battery.
Battery Life Expectancy:
Battery Type
If AlphaCell is selected, Accept, Float, Temperature Compensation, and Battery Capacity are not displayed.
NOTE:
48
017-877-B1-001 Rev. A
