Commissioning
Amatron+ BAG0082.2 10.10 23
Determine calibration value by travelling a cali-
bration distance:
 On the field, measure a calibration distance
of exactly 100 m. Mark the start and end
point of the calibration distance (Fig. 25).

Start the calibration.
 Travel the calibration distance exactly from
start to end point (upon starting, the counter
goes to 0). On the display the continuously
determined impulses are indicated.
 Stop after 100 m. On the display the num-
ber of determined impulses are now indi-
cated.

Adopt value Imp./100m.

Reject value Imp./100m.
Fig. 25
