Description of product
17
DB 534 02. 02
3. Description of product
The winter application spreader has been designed
for the rear 3-point linkage (cat. II) of a towing
vehicle.
The spreading discs are driven either by the PTO
shaft or a hydraulic motor.
D
4
9
2
0
5
H
a
s
b
e
r
g
e
n
-
z
u
l
.N
u
t
z
l
.
:
Ty
p
:
M
a
s
c
h
.
N
r
.
:
The spreader consists of the five components:
• Frame and hopper (1).
• Bottom group (2).
• Gearbox (3) or hydraulic motor (4) with spreading
disc (5).
• Agitator (6).
• multiple spread width reducer (7).
The spreader is as standard equipped with:
• Tractor-3-point linkage cat. I and II..
• Drive via Walterscheid PTO shaft (E+S) or
hydraulic motor (E+S H).
• Pre-selection switch for spread rate setting.
• Guard screen.
• Agitator.
1
2
3
7
4
5
6
