11.3.5 Diluting the excess residue in the spray liquid tank and spraying out the di-
luted residue remaining at the end of spraying operations
2. Drive the pump with pump operating speed.
3. Dilute the residual quantity with 10 times the amount of flushing
water.
4. Switch of the agitators.
5. Switch on sprayers on the control terminal.
→ If possible, first spray out the undiluted spray liquid from the
spray line on an untreated remaining area.
→ Spray out the diluted residual quantity on the treated area.
→ Keep flushing the diluted residues until air escapes from the
nozzles.
6. Switch off sprayers on the control terminal.
7. Cleaning the field sprayer.
When spreading residue, observe the maximum permissible applica-
tion quantity of the agent on areas already treated.
11.3.6 Emptying the spray liquid tank using the pump
the quick emptying is correctly connected to the
external tank and can draw liquid volumes.
4. Interrupt the pump drive.
5. Uncouple the hose.
