Layout and function of the basic implement
UX01 Super CP
Plus BAG0157.3 03.18
91
5.20 Transport and safety container (optional)
Transport and safety container for storing protec-
tive clothing and accessories.
5.21 Exterior wash down kit (optional)
Exterior wash down kit for cleaning the field
sprayer, includes
(1) Hose coiler,
(2) 20 m pressure hose,
(3) Spray gun
Operating pressure: 10 bar
Water output: 18 l/min
WARNING
Danger from liquids escaping under
pressure and contamination with
spray liquid if the spray gun is acti-
vated accidentally!
Secure the spray gun against uninten-
tional spraying using the locking
mechanism (1)
before each pause in spraying.
before depositing the spray gun
in its holder after cleaning work is
complete.
