UX01 Super CP
Plus BAG0157.3 03.18
247
17.2.4 Spray table for drag hose unit
AMAZONE Spray table with dosing disc 4916-26, (dia. 0.65 mm)
Pres-
sure
Nozzle output
per dosing disc
AUS application rate (l/ha)
/ km/h
Water
AUS
6
7
8
9
10
11
12
14
16
(bar)
(l/min)
1.0
0.20
0.18
71
61
53
47
43
37
36
31
27
1.2
0.22
0.19
78
67
58
52
47
43
39
34
29
1.5
0.24
0.21
85
73
64
57
51
47
43
37
32
1.8
0.26
0.23
92
79
69
61
55
50
46
40
35
2.0
0.28
0.25
99
85
74
66
60
54
50
43
37
2.2
0.29
0.26
103
88
77
68
62
56
52
44
39
2.5
0.31
0.27
110
94
82
73
66
60
55
47
41
2.8
0.32
0.28
113
97
85
76
68
62
57
49
43
3.0
0.34
0.30
120
103
90
80
72
66
60
52
45
3.5
0.36
0.32
127
109
96
85
77
70
64
55
48
4.0
0.39
0.35
138
118
104
92
83
76
69
59
52
AMAZONE spray table with metering disc 4916-32, (ø 0.8 mm)
Pres-
sure
Nozzle output
per dosing disc
AUS application rate (l/ha)
/ km/h
Water
AUS
6
7
8
9
10
11
12
14
16
(bar)
(l/min)
1.0
0.31
0.27
110
94
82
73
66
60
55
47
41
1.2
0.34
0.30
120
103
90
80
72
66
60
52
45
1.5
0.38
0.34
135
115
101
90
81
74
68
58
51
1.8
0.41
0.36
145
124
109
97
87
79
73
62
55
2.0
0.43
0.38
152
130
114
101
92
83
76
65
57
2.2
0.45
0.40
159
137
119
106
96
87
80
69
60
2.5
0.48
0.42
170
146
127
113
102
93
85
73
64
2.8
0.51
0.45
181
155
135
120
109
98
91
78
68
3.0
0.53
0.47
188
161
141
125
113
103
94
81
71
3.5
0.57
0.50
202
173
151
135
121
110
101
87
76
4.0
0.61
0.54
216
185
162
144
130
118
108
93
81
