ELECTRICAL, CHASSIS
SYSTEMS
Page 1
of2
Your motor home is equipped with three electrical systems:
the chassis 12-voIt DC system
_ the Fleetwood
12c:volt
DC
house system-
the Fleetwood 120-voltAC house system
They operate together to give you electrical power for many different
.
situations.
These electrical systems comply with all regulations and codes in effect
_
at the time the motor home was built.
The chassis
12-volt
DC
electrical system inCludes:
the vehicle batteries
engine charging system
ignition system
instrumel).t panel and control systems
the headlights, taillights,
tum
signals systems
other vehicle lights and accessories systems
The four locations for chassis fuses, breakers, relays, diodes, flashers
.
and solenoids are:
Front
Panel .................... Under the Dash Bonnet
Rear
PaneL
.................... Battery Compartment
Engine
Panel .................. Under the Bedtop Engine Access Lid
Chassis Frame ............... By the Engine
If
replacement of an electrical component is needed, use only equivalent
types as marked on the component.
See
section "50-Specifications" in this manual and the ,Electrical
section in the Chassis
Owner's
Mannal
for more information.
©
1996
Fleetwood Enterprises Inc.
American
Eagle
Wide
Body
ISSUE DATE: 6/96
All
rights
reserved
