33
MONITOR PANEL
Page
1
of3
.'
- .
The fluid monitor panel allows you to conveniently check the approximate
levels in the fresh, gray, black water holding
tanks, and
LP
tank. The
~lectrical
monitor panel allows checks 'of
·the
12-volt motor home and chassis battery
systems
and the charging status
of
the solarchargingsystem.
,
Monitor panel controls and display panels are located in the overhead
cabinet and in the exterior utility compartment.
FLUID MONITOR PANEL
Electrical probes installed in the tanks measurethe levels at various points
in the tanks.
.
-
.'
"~
.
.
C)
o FULL
CJ
FRESH
LP
03/4
0,1/2
.
C)
01/4
C)
GRAY BLACK
o EMPTY
..
~,
Fluid Monitor Panel
To
check tanki:evels:
Press
LP
GAS, WATER, or
HOLDING
TANK 1 or 2 rocker switches.
HOLDING
TANK 1 is the black water (toilet waste) tank, and
HOLDING
TANK
2 is gray water (sink and shower wastes).
The
E or empty indicator light will always
be
lit when the rocker switches
are depressed.
If
the tank is full, all lights will
be
on. Lights are sequential, and
indicate the level in approximately'l!4 tank
increments:lf the tank selected is
approximately
ll2~full,
for example, lights
E,
1/4 and 1/2 will be on. _
© 1996 Fleetwood
Enterprises
Inc.
American Eagle
Wide
Body
ISSUE DATE: 6/96
All
rights
reserved
