AMETEK CTS Automotive Transient Immunity Testing
1.00 15 / 26
11 USB interface
Serial USB interface port to remote control the generator by software
This interface is only available for iso.control software tool
12 GPIB / IEEE 488
Parallel interface GPIB / IEEE 488 to remote control the generator by software tool
13 Remote control connector CN
EM Test internal interface to be connected to other generators, currently not in use
14 Fail detection FAIL 1 (TEST STOP)
The BNC input FAIL 1 can be used for DUT monitoring. In case of a low going signal (to chassis ground) the
UCS 200N will stop pulse generation and the actual running test routine is interrupted. The test routine can be
restarted by pressing start again.
15 Fail detection FAIL 2 (TEST PAUSE )
The BNC input FAIL 2 can be used for DUT monitoring In case of a low going signal (to chassis ground) the
UCS 200N will stop pulse generation and the actual running test routine is paused as long as the low level
signal is available at the FAIL 2 input. The test routine continues automatically as soon as the low level signal
goes to high level. A message of FAIL 2 is indicated in the LCD display as well as in the iso.control software.
