AMETEK CTS Automotive Transient Immunity Testing
1.00 18 / 26
9 START / STOP Button
Button for Start and Stop the test. The LED indicates the status.
- Sequence ( Test in progress)
- Endless
10 MODE Button
Button for Mode selection depend the mode definition in Ford FMC1278 and EMC-CS-2009 standard
11 PULSE Button
Pulse selection with LED indication. Cyclic selection of test procedures A1, A2-1, A2-2, (C-1), C-2, F
12 ID Button
Button for test selection cyclic rotation of the tests CI220, CI 260, RI 130
13 TEST ON Button
Button for switch on/off the power to the DUT
14 Trigger OUT (BNC)
Trigger output from the internal controller unit
15 Trigger IN (BNC)
Trigger input (E) for relays 1 trigger. Max. trigger input voltage= 35V
