6-16 | Model 931S / Model 932S UV Analyzers
Figure 6-5 illustrates an Optical Bench Assembly from a Model 932S
Analyzer. However, the lamp replacement procedure is the same for a
Model 931S Analyzer.

NOTE
Figure 6-5.
Model 932S Optical
Bench Assembly.
