Controller / User Interface | 4-31
‘**’ following the parameter names below indicates the parameter
should only be modified by a trained technician.
See also “Optical Bench Temperature Control,” “Measuring Cell
(Oven) Temperature Control (Optional),” or “Heated Acid Gas
Sample Probe Temperature Control (Optional)” in the following
pages.
Bench
The measure Range (°C) for the Optical Bench.
Cell
The measure Range (°C) for the Measuring Cell.
Probe
The parameters for the optional Heated Acid Gas Probe temperature
zone. The Probe temperature zone is optional (AMETEK Heated Acid
Gas Sample Probe required).
Temperature Control
The Temperature Control dialog box contains temperature control param-
eters for all of the temperature zones measured by the analyzer.
NOTE
Figure 4-12.
Temperature Control
dialog box.
Setup (tab)Temp
Control
Alarm Indicator box
NOTE
