Ametek VDS 200Q Series - General Specifications; Environmental Conditions

AMETEK CTS VDS 200Q Series
Manual for Operation V 1.3.1 29 / 36
5.5.
General
Dimensions
Device in Rack
HU
Dimensions
H x W x D*
Weight
VDS 200Q25.2
19” Rack
25 HU
132 x 55 x 80 cm
230 kg
VDS 200Q50.2
19” Rack
25 HU
132 x 55 x 80 cm
275 kg
VDS 200Q100.2
19” Rack
38 HU
194 x 55 x 80 cm
450 kg
VDS 200Q150.2
Double 19” Rack,
38 HU
185 x 111 x 80 cm
700 kg
VDS 200Q200.2
Double 19” Rack,
38 HU
185 x 111 x 80 cm
900 kg
*Rack depth is 80mm with the mains connector protruding a approx 2-3cm out of the back of the rack, depending
on the model.
CAUTION:
The simulator has high inrush as well as leakage current. Use pluggable equipment type B
connections according to IEC 309 to avoid tripping the breaker in the laboratory.
Supply voltage, Fuses and input current
Device
Mains
Phases
Supply
Voltage U
eff
Primary Current I
eff
Inrush at start
Circuit Breaker*
VDS 200Q25.2/100
1
100 V ±10%
25 A
RMS
1 x 25A
VDS 200Q25.2/120
1
120 V ±10%
24 A
RMS
1 x 25A
VDS 200Q25.2/230
1
230 V ±10%
12 A
RMS
1 x 16A
VDS 200Q50/200
3
200 V ±10%
Typ. 16 A
RMS
/phase
1 x 25A
VDS 200Q50/400
3
400 V ±10%
Typ. 9 A
RMS
/phase
225A
1 x 16A
VDS 200Q100.2/400
3
400 V ±10%
Typ. 16A
RMS
/phase
450A
2 x 16A*
VDS 200Q150.2/400
3
400 V ±10%
Typ. 25A
RMS
/phase
675A
3 x 16A*
VDS 200Q200.2/400
3
400 V ±10%
Typ. 30A
RMS
/phase
900A
4 x 16A*
* The power supplies for the system are in parallel. For example, the 100A version contains two 16A three-phase
breakers, making the total maximum current draw before shutdown 32A/phase.
Power Consumption and Heating
As a class A amplifier the VDS 200Q-series consumes nearly as much power in with no load as with full load as
seen in the following table.
VDS 200Q25.2
VDS 200Q50.2
VDS 200Q100.2
VDS 200Q150.2
VDS 200Q200.2
0% I
MAX
, 0V
340 W est.
688 W
1404 W
2222 W
3024 W
50% I
MAX
, 80V
420 W est.
843 W
1538 W
2340 W
3000 W
80% I
MAX
, 80V
500 W est.
1104 W
1685 W
2875 W
3580 W
For the purpose of cooling, the power consumed by the DUT must be added.
5.6.
Environmental conditions
Temperature range:
Operation at +10 to +45°C Storage and transport at -10 to +60°C
Humidity:
30 to 70% (non condensing)
Pressure:
860 to 1060 hPa
Protection Class:
IP20
