8-2
SERIAL Port
SERIAL Port
Connector type:
D825
male
In
the
following table, column two gives
the
Amiga pin assignments.
Columns
three
and
four give
pin
assignments
for
other
commonly
used connections;
the
information
in
these
two columns
is
given for
comparison only.
Caution Pins 9 and 10 on the Amiga serial connector are used
for external power. Connect these pins ONLY if
power from them is required by the external device.
The table lists the power provided by each of these
pins.
Pin 7 is the system ground. Do not connect this to
shield ground on Pin 1.
