and NIT Search on/off. After you set up, press
[OK] key to start scanning.
2 Press [green] button to edit the name and
longitude of the select satellite.
3 Press [yellow] button to add a new satellite.
4 Press [blue] button to delete one or more satellites
that you have selected.
5 Press [white] button to move the satellite selected
(note: you can only move one satellite).
10.2 FastScan Satellite
In this menu, you can perform a fastscan by
selecting the provider and press OK button on
Start Search item.
10.3 Auto installation
“Auto Installation” is a very new and convenient
function. It will automatically detect all dishes
connected to this machine and scan the available
services belonging to the satellite matched
according to satellites and transponders data in
current database. You don’t have to input any
parameter of your antenna settings. Just press
“ OK ” button to enter this “Auto Installation” menu
then it starts scanning and shows you the result at
the end of scan.
10.4 Satellite Guide
When you enter “Satellite Guide” menu, you will
see the screen like below:
“Satellite Guide” is used for user to enter local
longitude; local latitude and satellite longitude. By
the evaluation from the receiver evaluate the
antenna azimuth and antenna elevation; user can
follow this guidance to adjust antenna.
6 You can use numeric keys to input
parameters in “Local Longitude”, “Local
Latitude” and “Satellite Longitude”.
7 You can use [Left/Right] key to select east or
west in “Local Longitude” and “Satellite
Longitude”, select north and south in “Local
Latitude”.
8 Moving highlight to “Start” item and press
[OK] key. The lower column on the screen will
calculate the corresponding value
automatically.
9 Orientation means the angle between south
and satellite.
10 Press [MENU] key to draw back to “Main”
Menu.
10.5 Terrestrial Installation
Press [OK] key to enter the selected item.
