For a description of the Air Unit LEDs, you may refer to:
• Table 3: Air Unit – Power LED
• Table 4: Air Unit – Video LED
• Table 5: Air Unit – Network LED
Air Unit Accessories
The box number in which each cable is provided is indicated below.
Tx Cable Antennas
Two flat lightweight 2dbi cable antennas. Box 2.
Figure 3: Flat Tx Cable Antennas
Cable Antenna Mounting Accessories
Plastic accessories for mounting the antennas on the aircraft. Box 2.
Figure 4: Cable Antenna Mounting Accessories
Micro to Mini HDMI Cable
Micro to Mini (Right Angled) – 50cm length. Box 1A.
Figure 5: Micro to Mini HDMI Cable
