CONNEX
TM
User Guide
33
Alert and System Messages
The following describes the messages that may appear on the monitor connected to
the Ground Unit HDMI port.
Alert Messages – Overlaid on Video during Link
These alert messages may be displayed on top of the live video.
Table 10: Alert Messages
Out of Range
A link still exists, but the video signal has been lost. This message is
displayed regardless of the OSD button position.
Approached
Range Limit
Is displayed for 30 seconds, from the moment the Air Unit has been
detected as out of range until the Out of Range warning is displayed. This
message represents a warning that the video signal is about to be lost. We
recommend flying the aircraft back within the range of the Ground Unit.
When the aircraft is within range, the video signal is automatically
reacquired. This message is only displayed if the OSD button enables OSD
display.
Video Signal Not
Detected
A link has been established between the Air Unit and the Ground Unit, but
no video signal has been detected. This message is displayed regardless of
the OSD button position.
System Messages – No Link
These system messages may be displayed when no live video is displayed.
Table 11: System Messages (in Link)
Searching for Air Unit
This message is displayed until a link is established.
This may occur when the Air Unit is out of range,
unavailable or has removed the Ground Unit from
its list of paired devices.
Starting Pairing Process Press OK to continue.
Pairing in Progress
Is displayed while the Air Unit is pairing with a
Ground Unit.
