2.5. Machine description
View from the right
1 - 1-point lifting eye
2 - Identication plate
3 - Drum scraper
4 - Rear bonnet closure
5 - Front bonnet closure
6 - Front infrared sensor
View from left
7 - Articulated joint protection
8 - Shutdown bar (optional)
9 - Cockpit cover
10 - Rear infrared sensor
11 - Light indication
