8.1.6 Master Reset
Master Reset facility is only active when the ECP is in the Manual mode.
When pressed all zone outputs switch to the off channel but only if there are NO unacknowledged
EAID or FACP alarm signals in the OWS.
8.1.7 Lamp Test Facility
The LAMP TEST facility causes all the front panel indicators (on the master control panel only) to
illuminate and the audible buzzer operates for 3 seconds then resets.
The following indicators are not included;
1. Mains On,
2. System on Batteries,
3. Charger Fault,
4. Battery Fault and
5. Battery Isolated
The LAMP TEST is invoked by momentarily pressing the LAMP TEST button.
8.1.8 System Test Facility
This facility allows the testing of the evacuation sequence fitted without broadcasting signals.
To invoke a test of the sequence:
1. Place keyswitch into ISOLATE position
2. Press SYSTEM TEST
3. Press the CANCEL button for the OWS zone input to simulate an alarm.
4. System should indicate the sequence but not output any audio signals.
5. To restore system to normal return keyswitch to AUTO.
The LAMP TEST is invoked by momentarily pressing the LAMP TEST button.
8.1.9 System Status Indicators
There are twelve system status indicators each illuminated when;
1. Power On Mains power is present at ECP.
2. System On Batteries The ECP is operating from batteries.
3. Charger Fault The battery charger fails.
4. Battery Fault The battery voltage drops below the lower limit.
5. Battery Isolated The batteries have been isolated from the charger i.e. fuse is blown
or circuit breaker is tripped.
6. Signal Fault The signal/speech generator has failed.
7. Alarm system Isolated The alarm system is isolated.
8. Comms Fault A fault is detected in the communications bus.
9. System Fault Any ECP or RPC has a module fault.
10. Module Fault A module fault within the ECP's internal communication bus.
11. Microphone Fault The microphone/BGM mixer has failed.
12. Remote ECP In Control See MANUAL POSITION for the key-switch.
