9 Installation
9.1 Unpacking And Inspection
Carefully check packing prior to unpacking goods for any external transit damage. Unpack the goods
and check the goods both externally and internally for any loose or damaged components or any
problem which may affect the appearance, installation or operation of the goods.
Ensure all wiring harnesses are secure, all plugs are correctly fitted into their sockets, each circuit
board is secure, and that all fixings and earth studs are tight.
If a plug-in type circuit board or ribbon connector becomes dislodged in transit, replace it in its socket
and ensure that it is correctly mated.
If any damage has occurred you are to contact Ampac in writing within 14 days of receiving the
goods in accordance with the Ampac Terms of Sale.
If the goods are of a nature which are accompanied by an Operators Manual you are requested to
complete the Damage Report Form and return it to Ampac (Head Office) within 14 days of receiving
the goods, in lieu of the written notification.
9.2 Anti-Static Precautions
To prevent damage to panel components please ensure prior to touching or handling any of the
wiring or printed circuit boards within the OWIS that you are correctly earthed. The recommended
method for personnel earthing is to use an anti static wrist strap and a flexible lead. Fit the wrist strap
to yourself and attach the flexible lead to the cabinet earth bolt located inside the top of the cabinet.
Printed circuit boards removed from OWIS should be immediately placed in the anti static bags
provided in the installation and maintenance kit.
9.3 Working On The System
To prevent damage to panel components please ensure prior to unplugging any connector,
connecting or disconnecting any wiring, removing or replacing any module or board, that both the
Mains and Batteries have been isolated. Batteries can be isolated by removing the system fuse
mounted on the backpan.
9.4 Cabinet Installation
The EV3000 Cabinet may be surface or recess mounted. All indicators and controls shall be not less
than 750mm and not more than 1850mm from the floor level.
9.4.1 Surface Mount
For surface mount the EV3000 Cabinet is secured by four bolts or screws through pre-drilled 12mm
holes on the rear of the cabinet.
9.4.2 Recess Mount
For a recess mounting EV3000 Cabinet allow a cut-out equal to the size of the Cabinet plus 10mm
all round clearance. The standard surround is 50mm wide and is secured with screws from the inside
of the cabinet. Seal all unused knockouts and cable entries to prevent water or moisture entering the
cabinet.
