2 CORE 0.75mm (NOT F.R.)
1 PAIR 0.75mm TWISTED SCREENED AUDIO (NOT F.R.)
1 PAIR 0.75mm TWISTED SCREENED DATA/AUDIO *
CABLE TYPE LEGEND
* RADOX SERIES FR COMMUNICATION
MUST BE SINGLE PAIR.
NOT
USED
NOT
USED
NOT
USED
LOOP ADDRESS 6
LOOP ADDRESS 5
LOOP ADDRESS 4
LOOP ADDRESS 1
LOOP ADDRESS 2
LOOP ADDRESS 3
NOTES:
1. MAXIMUM NUMBER OF LOOP MODULES IS 50
2. REMOTE PAGING CONSOLES CAN EITHER
BE POWERED FROM AN ECP OR THEIR OWN
9VDC PLUGPACK(OPTIONAL).
3. THIS IS A TERMINATION DRAWING REFER
TO DRAWING G0010 SHT DBE FOR GENERAL
SYSTEM LAYOUT.
4. THIS DRAWING IS FOR INFORMATION ONLY
REFER TO AMPAC FOR SPECIFIC
APPLICATIONS.
240V AC
9 VOLT
PLUG PACK
1.7A
(OPTIONAL)
-VE
+VE+VE
-VE
+VE
-VE
GND
GND
-VE
+VE
+VE
-VE
GND
GND
-VE
+VE
+VE
-VE
GND
RPC
AUDIO
BUS
RPC
POWER
RS485
COMMS
OUT
OWS
AUDIO
BUS
OIS
AUDIO
BUS
RS485
COMMS
IN
MASTER EMERGENCY
CONTROL PANEL
SECONDARY EMERGENCY
CONTROL PANEL
RS485
COMMS
IN
OIS
AUDIO
BUS
OWS
AUDIO
BUS
RS485
COMMS
OUT
RPC
POWER
RPC
AUDIO
BUS
GND
-VE
+VE
+VE
-VE
GND
GND
-VE
+VE
+VE
-VE
GND
GND
-VE
+VE
-VE
+VE+VE
-VE
DATA GATHERING
PANEL
RS485
COMMS
IN
OIS
AUDIO
BUS
OWS
AUDIO
BUS
RS485
COMMS
OUT
RPC
POWER
RPC
AUDIO
BUS
GND
-VE
+VE
+VE
-VE
GND
GND
-VE
+VE
+VE
-VE
GND
GND
-VE
+VE
-VE
+VE+VE
-VE
REMOTE PAGING CONSOLE
14131211109
8765432
15
1
REMOTE PAGING CONSOLE
14131211109
8765432
15
1
REMOTE PAGING CONSOLE
14131211109
8765432
15
1
COMMS IN +VE
COMMS IN -VE
COMMS IN SHIELD
COMMS OUT +VE
COMMS OUT -VE
COMMS OUT SHIELD
AUDIO +VE
AUDIO -VE
MIC SHIELD
POWER +9VDC
POWER -0V
NOTE: EACH +VE AND -VE
PAIR IS TWISTED TOGETHER
BLACK 2.5mm
RED 2.5mm
GREEN 1mm
BLUE 1mm
ORANGE 1mm
THESE
PAIRS
TWISTED
REMOTE PAGING CONSOLE
9. N/C
10. COMMS OUT GND
11. COMMS OUT -VE
12. COMMS OUT +VE
13. COMMS IN GND
14. COMMS IN -VE
15. COMMS IN +VE
1. POWER -VE
2. MIC GND
3. MIC -VE
4. MIC +VE
5. N/C
6. N/C
7. N/C
8. POWER +VE
14131211109
8765432
15
1
