16 Appendix A: Zone Labelling
ECP ZONE LABELLING
Normally AMPAC panels are supplied with labelling installed as per the customers requirements.
These are supplied in the format shown below for both the OWS and OIS.
Each zone identifier can contain up to four (4) lines of text each being nine (9) characters long.
REF
15.00 mm
REF
8.20 mm
23.50 mm 38.80 mm 54.00 mm 69.30 mm 84.50 mm 99.80 mm
115.00 mm 125.00 mm
Material 0.5mm Card
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8
Figure 35: EV3000 Label Requirements
(ACTUAL WINDOW USEABLE SIZE 120mm x 10mm)
