EV3000 INSTALLATION & COMMISSIONING
EAID.
Open Cable Between EAID and WIP.
No EOL Resistor At EAID.
Install 10k EOL.
OWS Zone Fault.
Visual.
Visual Cabling Faulty.
Open Or Short Circuit Cable To Visual Line Fuse
On Visual Output Connection Board Down.
Check Cabling And Connections.
Replace Fuse 1amp.
OWS Zone Fault.
Alarm System.
Alarm System Cabling Faulty.
Open Circuit Cable To Alarm System.
No EOLResistor At Alarm System
Faulty FACP Input Connection Board.
Check Cable And Connections.
Install 10k Resistor At Alarm System End
Of Cable.
Replace Board.
OIS Zone Fault.
WIP Cabling Faulty.
Line Fuse On OIS Selector Board Blown 302-615.
Check Cable And Connections.
Replace Fuse Pico 1 Amp.
Check As Per Clause 3.3 In EV3000
Commissions Report.
OWS Zone Fault.
No Fault Indication In
Zone Status.
Faulty Common BGA On Panel.
Check 10k EOL Installed.
Check BGA Ok.
Check Wiring From Panel BGA To
302-4790 Master Keyswitch Panel.
