Page 25
EV3000 INSTALLATION & COMMISSIONING
10.4 100V Line Speaker Connections
Two termination boards are available for termination of the field speaker circuits. Both boards have
the same terminal designations.
The 302-490X was the original board and has been replaced by the BRDEV3FTB2. The
BRDEV3FTB2 has filter circuitry for each speaker circuit. The filter circuit supresses any unwanted
noise from the speakers when the speaker circuit is not in use (generally only an issue in apartment
type installations – especially at night when there is low ambient noise)
10.4.1 Connections
Field Connections
Use
TB1 - 1, 2
Output Evac Zone 1
TB1 - 3, 4
Output Evac Zone 2
TB2 - 1, 2
Output Evac Zone 3
TB2 - 3, 4
Output Evac Zone 4
TB3 - 1, 2
Output Evac Zone 5
TB3 - 3, 4
Output Evac Zone 6
TB4 - 1, 2
Output Evac Zone 7
TB4 - 3, 4
Output Evac Zone 8
TB5 - 1, 2
Volume Control Override
Factory Connections
Use
CN1
Outputs from amplifiers 1 and 2
CN2
Outputs from amplifiers 3 and 4
CN3
Outputs from amplifiers 5 and 6
CN4
Outputs from amplifiers 7 and 8
CN5
Individual zone volume control outputs
TB7 -1
0V
TB7 -2
Common volume control
TB7 -3
27V
10.4.2 Fusing
Fuse
Use
Rating
F1
Volume Control Override
1 Amp = 302-4900
3 Amp = BRDEV3FTB2
