6-76
6
MODE – C
GROUP – 1: PROGRAMMABLE INPUT / OUTPUT SELECTION
C101 ~ C106: PSI-1 ~ 6
C114 ~ C115: PSI-RUN~STOP
User can configure eight programmable sequence inputs for different functions using parameters
C101 ~ C106 and C114 ~ C115. The status of the Programmable Sequence Input can be monitored
in M307. The various options are explained as under.
OPTION FUNCTION NAME FUNCTION
1 Not Used Indicates that no function is selected on the PSI.
2 Jog Select This is a jog command. If this signal is O
N while RUN is OFF,
operation then conforms to the setting of jogging speed. For stoppage,
either ramp down stop or coast to stop is available.
3 Ramp select Acceleration / Deceleration ramp performance is switched over.
Acceleration / Deceleration Time-2
is available with ON, and
Acceleration / Deceleration Time-1 is available with OFF.
4 Preset i/p-0
The Preset Speed 0~7 are selected as per the binary combination of
the Preset i/p-0 ~ 2.
5 Preset i/p-1
6 Preset i/p-2
7 Freq Increase The currently
selected frequency setting is increased or decreased.
When the ON state continues, the frequency is incremented
/decremented with 0.1Hz at every 100msec. This is valid only if static
potentiometer is selected as frequency reference source in A106
8 Freq Decrease
9 Aux Drive
The auxiliary drive setting is validated with this signal. This operation
is valid during the AC Drive stopping.
10 Emergency stop –
NO
This is used as emergency stop. This is Normally Open type. When
the digital input (connected to C
OM in case of sink logic or to +24V in
case of source logic) is Close, Emergency stop occurs as per the
selection in C503.
11 Fault Reset
This is used for the fault reset. If RUN
input is present at the time of
fault reset, the AC Drive will not start after fault reset.
Issue fresh RUN
command to start the AC Drive after fault reset.
12 Ext Fault - NO
This is used for the external fault function. This is Normally Open type.
When the digital input (connected to COM in case of sink logic and to
+24V in case of source logic) is Close, external fault occurs.
13 Reverse
This input is used to select reverse direction of rotation in terminal
mode.
Note that this will not function when RSF and PR function
are selected in E101.
14 Terminal When this input is sele
cted, the operation control will be switched over
to terminal.
15 Ref Select 0
These two inputs are
used to select the
frequency reference
as shown in the side
table.
Ref Select 1 Ref Select 0
Freq reference
0 0
A106
16 Ref Select 1 0 1
A110
1 0
A111
1 1
A112
17 PR Step Skip
When this input is selected, it will skip the present step during Pattern
Run operation. Only applicable to Pattern Run function.
