PSO2 6 Freq Attain
PSO3 1 Not Used
PSO4 1 Not Used
C111 ~ C112: Programmable Relay-1 ~ 2
C113: Programmable Fault Relay
User can configure two programmable relays for different functions using these parameters. The
status of the Programmable Relay can be monitored in M308. The options are same as PSO.
The default settings are as under.
Programmable Relay-1 2 Run
Programmable Relay-2 1 Not Used
Programmable Fault Relay 25 Fault
GROUP – 2: ANALOG OUTPUT SELECTION
C201 ~ C202: Vout-1 ~ 2
User can configure two programmable analog outputs (0~10V) for different functions using
parameters C201 ~ C202.
1 Output Freq The analog output will correspond to the output frequency (0~A103).
2 O/P Current The analog output will correspond to the output current (0~200%).
3 Output Power The analog output will correspond to the output power (0~B106).
4 Output Volt The analog output will correspond to the output voltage (0~100%).
5 DC Bus Volt The analog output will correspond to the dc bus voltage (0~800).
6 PID Output The analog output will correspond to the PID Output (0~100%)
7 Heat sink Temp.
The analog output will correspond to the heat sink temp. (0~100 °C)
8 PLC A-O/P 1 The analog output will correspond to the PLC A-O/P 1 (0~1000d).
9 PLC A-O/P 2 The analog output will correspond to the PLC A-O/P 2 (0~1000d).
10 PLC A-O/P 3 The analog output will correspond to the PLC A-O/P 3 (0~1000d).
11 PLC A-O/P 4 The analog output will correspond to the PLC A-O/P 4 (0~1000d).
12 Unipolar Torque
Current
The analog output will correspond to the torque current (0~200%).
13 Excitation
Current
The analog output will correspond to the excitation current (0~200%).
14 Set Frequency
The analog output will correspond to the Set frequency (M105).
15 Bipolar Torque
Current
The analog output will correspond to the torque current (-200~200%).
The default setting of the programmable analog outputs are as under.
VO1 1 Output Freq
VO2 2 O/P Current
