Axpert-Eazy AC Variable Frequency Drive
6-105
6
GROUP-2: MODE SELECTION FOR PATTERN RUN TABLE-2
G201- G215: PR Mode T2 – STP1 ~ STP15
Select the required mode for pattern run function for each step of Table-2
=1: STOP
=2: FORWARD
=3: REVERSE
GROUP-3: PATTERN TIME FOR TABLE-1
G301- G315: PR Time T1 – STP1 ~ STP15
Select the required time for pattern run function for each step of Table-1
GROUP-4: PATTERN TIME FOR TABLE-2
G401- G415: PR Time T2 – STP1 ~ STP15
Select the required time for pattern run function for each step of Table-2
GROUP-5: RETURN STEP FOR TABLE-1
G501- G515: Return Step T1 – STP1 ~ STP15
Select the return step for pattern run function for each step of Table-1
GROUP-6: RETURN STEP FOR TABLE-2
G601- G615: Return Step T2 – STP1 ~ STP15
Select the return step for pattern run function for each step of Table-2
