Amtech
6-112
6
16
-
bit
Register
No.
Name Access Type Details Value
94 FSV Input Read Read input value from FSV 100d = 100%
95 FSI Input Read Read input value from FSI 100d = 100%
96 Vin Input Read Read input value from Vin 100d = 100%
97 Iin Input Read Read input value from Iin 100d = 100%
98-100 Reserved -- -- --
101 Panel Parameter 1 Read Read value set with C701 --
102 Panel Parameter 2 Read Read value set with C702 --
103 Panel Parameter 3 Read Read value set with C703 --
104 Panel Parameter 4 Read Read value set with C704 --
105 Panel Parameter 5 Read Read value set with C705 --
106 Panel Parameter 6 Read Read value set with C706 --
107 Panel Parameter 7 Read Read value set with C707 --
108 Panel Parameter 8 Read Read value set with C708 --
109 Panel Parameter 9 Read Read value set with C709 --
110 Panel Parameter 10 Read Read value set with C710 --
111 Panel Parameter 11 Read Read value set with C711 --
112 Panel Parameter 12 Read Read value set with C712 --
113-114 Reserved
All 100 numbers of 1-bit flags are Read/Write, and one 32-bit register is Read/Write.
In-built PLC Command Format:
The PLC commands used with the In-built PLC are 12- digit value shown in below table. These
commands can be input from the P101 to PA10 parameter.
0 0 2 0 0 1 0 2 5 0 0 0
OPCODE
DATA1
DATA2
DATA3
12-digit In-built PLC Command format
Where, OPCODE = Command no.
DATA1 = Data format 1
DATA2 = Data format 2
DATA3 = Data format 3
 Note: Range of DATA1, DATA2 and DATA3 are different and it depends on command type. See list of
PLC Commands for detail. It is necessary to terminate program with END (000) Command.
