Axpert-Eazy AC Variable Frequency Drive
6-133
6
P408 043000000000
P409 047025001000 If PSI is given then it will reset all Registers and total quantity input.
P410 041025000000
P501 001005000000
P502 001020000000
P503 001007000000
P504 001006000000
P505 001009000000
P506 001056000000
P507 00103000000
P508 061003009000
P509 061005056000
P510 043000000000
P601 061002007000 To Display values of registers.
P602 061004009000
P603 061005056000
P604 061006020000
P605 061007030000
P606 000000000000 End of program
User has to set following parameter.
1. Enable PLC function from C312.
2. Register 94 contains FSV input, which is read only memory location.
3. Register 108 contains value of Panel Para8 (C708) which is used for multiplication factor,
and that should be change as per input quantity range.
4. Select 28 no. Selectable option in C101.
5. C701 = 10 and C702 = 100. (10*100 = 1000 count for Timer1)
Note: There is only one 32-bit memory location is given.
During 32-bit load and store commands user should use only 0 to 84 16-bit memory locations.
