Amtech
6-134
6
Example 8
This application is to demonstrate Low Pass filter command.
Program Code:
Input from Display Panel into P101 to PA01
P101 063001094030 Input is Register 94(FSV) and Time constant is 030. LPF output will
be in Register 1.
P102 061001001000 Output is displayed on Display Para1.
P103 000000000000 End of program
User has to set following parameter.
1. Enable PLC function from C312.
2. Register 94 contains FSV input, which is read only memory location.
