Amtech Axpert-Eazy Series - Appendix-A Standard Specifications

Axpert-Eazy AC Variable Frequency Drive
A.1
13
A
Appendix-A: Standard Specifications
Power Source
380 ~ 480VAC, 3-Phase, 3-Wire, 50/ 60 Hz
Tolerance
Voltage tolerance: -15%, +10%, Frequency tolerance: ±5%
AMT
-
XXX
-
4
037 045 055 075 090 110 132 160 200 250 315 355 400 450 500 630 710 800 900 11E 14E 15E 18E
Normal Duty
Rated Capacity (Hp)
50 60 75 100 125 150 175 215 275 335 420 475 535 600 670 845 950 1075 1200 1500 1875 2075 2415
Max Continuous Rated
Current (A) (Note: 1)
72 87 110 147 175 215 245 320 360 470 530 600 704 800 844 1067 1205 1440 1613 1992 2500 2700 3200
Max Applicable Motor
(kW) (Note: 2)
37 45 55 75 90 110 132 160 200 250 315 355 400 450 500 630 710 800 900 1120 1400 1550 1800
Overload Current Rating 120% for 60 seconds, 140% for 2.5 seconds every 5 minutes
Heavy Duty
Rated Capacity (Hp)
40 50 60 75 100 125 150 175 215 275 335 420 475 535 600 670 845 950 1075 1200 1500 1875 2075
Max Continuous Rated
Current (A) (Note: 1)
60 72 87 110 147 175 215 245 320 360 470 530 600 704 800 844 1067 1205 1440 1613 1992 2500 2700
Max Applicable Motor
(kW) (Note: 2)
30 37 45 55 75 90 110 132 160 200 250 315 355 400 450 500 630 710 800 900 1120 1400 1550
Overload Current Rating 150% for 60 seconds, 175% for 2.5 seconds every 5 minutes
Power Source
500 ~ 575VAC, 3-Phase, 3-Wire, 50/ 60 Hz
Tolerance
Voltage tolerance: -15%, +10%, Frequency tolerance: ±5%
AMT
-
XXX
-
5
037 045 055 075 090 110 132 160 200 250 315 355 400 450 500 630 710 900 10E 12E 14E 15E 18E
Normal Duty
Rated Capacity (Hp)
50 60 75 100 125 150 175 215 275 335 420 475 535 600 670 845 950 1200 1340 1675 1875 2075 2415
Max Continuous Rated
Current (A) (Note: 1)
54 73 87 110 135 150 175 215 290 345 390 430 485 540 670 720 950 1060 1335 1400 1680 1720 2050
Max Applicable Motor
(kW) (Note: 2)
37 45 55 75 90 110 132 160 200 250 315 355 400 450 500 630 710 900 1000 1250 1400 1550 1800
Overload Current Rating 120% for 60 seconds, 140% for 2.5 seconds every 5 minutes
Heavy Duty
Rated Capacity (Hp)
40 50 60 75 100 125 150 175 215 275 335 420 475 535 600 670 845 950 1200 1340 1675 1875 2075
Max Continuous Rated
Current (A) (Note: 1)
46 54 73 87 110 135 150 175 215 290 345 390 430 485 540 670 720 950 1060 1335 1400 1680 1720
Max Applicable Motor
(kW) (Note: 2)
30 37 45 55 75 90 110 132 160 200 250 315 355 400 450 500 630 710 900 1000 1250 1400 1550
Overload Current Rating 150% for 60 seconds, 175% for 2.5 seconds every 5 minutes
Power Source
600 ~ 690VAC, 3-Phase, 3-Wire, 50/ 60 Hz
Tolerance
Voltage tolerance: -15%, +10%, Frequency tolerance: ±5%
AMT
-
XXX
-
6
037 045 055 075 090 110 132 160 200 250 315 355 400 450 500 630 710 900 10E 12E 14E 17E 18E 21E
Normal Duty
Rated Capacity (Hp)
50 60 75 100 125 150 175 215 275 335 420 475 535 600 670 845 950 1200 1340 1675 1875 2275 2415 2815
Max Continuous Rated
Current (A) (Note: 1)
46 54 72 87 110 135 150 175 215 290 345 387 426 482 537 662 713 941 1058 1327 1396 1680 1720 2050
Max Applicable Motor
(kW) (Note: 2)
37 45 55 75 90 110 132 160 200 250 315 355 400 450 500 630 710 900 1000 1250 1400 1700 1800 2100
Overload Current Rating 120% for 60 seconds, 140% for 2.5 seconds every 5 minutes
Heavy Duty
Rated Capacity (Hp)
40 50 60 75 100 125 150 175 215 275 335 420 475 535 600 670 845 950 1200 1340 1675 1875 2275 2415
Max Continuous Rated
Current (A) (Note: 1)
37 46 54 72 87 110 135 150 175 215 290 345 387 426 482 537 662 713 941 1058 1327 1396 1680 1860
Max Applicable Motor
(kW) (Note: 2)
30 37 45 55 75 90 110 132 160 200 250 315 355 400 450 500 630 710 900 1000 1250 1400 1700 1800
Overload Current Rating 150% for 60 seconds, 175% for 2.5 seconds every 5 minutes
