Axpert-Eazy AC Variable Frequency Drive
6-1
6
CHAPTER-6: PARAMETER SETTINGS & FUNCTIONS
MODE-M: Monitor Parameters
The monitor parameters display various information like operating parameters, status of various
signals, software version, fault history etc…
M101
Output Frequency Hz 0.01 It displays the output frequency. If the AC DRIVE is off, it will display
zero.
M102
Motor Speed rpm 1 It displays the motor speed or shaft rpm.
If A401=1, 3, 5, 7: It displays the calculated motor speed or shaft rpm
using line speed setting A105 or D205 and M101.
If A401=2, 4, 6, 8: It displays the actual speed of motor shaft using
encoder.
M103
Output Current Amp
0.1 It will display the output current. If the AC DRIVE is
OFF
, it will display
zero.
M104
Output Current %L 1
The output current is displayed as % of motor rated current B103.
M105
Set Frequency Hz* 0.01 The currently selected frequency setting value is displayed.
M106
Frequency Reference
Input
The currently selected frequency setting input point in A106 or D204 will
be displayed.
M107
Set Torque % 0.1
The current value of torque setting is displayed in vector control mode.
M108
Torque Reference Input
The currently selected torque setting input point in A108
in vector control mode only.
M109
PID Reference 0.1 Displays the value of currently selected
PID
reference in the unit selected
in C614.
M110
PID Feedback 0.1 Displays the value of currently selected
PID
feedback in the unit selected
in C614.
M111
FSV Input Voltage V 0.1 Display the analog input voltage at FSV.
M112
FSI Input Current mA 0.1 Display the analog input current at FSI.
M113
VIN Input Voltage V 0.1 Display the analog input voltage at VIN.
M114
IIN Input Current mA 0.1 Display the analog input current at IIN.
M115
Output Current U Amp
0.1 Display the Output current of U phase.
M116
Output Current V Amp
0.1 Display the Output current of V phase.
M117
Output Current W Amp
0.1 Display the Output current of W phase.
M201
Input Voltage Vry Vac 1 Displays Input Vry Voltage. This may differ from the actual i/p voltage.
M202
Input Voltage Vyb Vac 1 Displays Input Vyb Voltage. This may differ from the actual i/p voltage.
M203
Output Voltage Vac 1 Displays output voltage command. The display may differ from the
output voltage. It depends on the power supply voltage. It will display
zero when AC DRIVE is
OFF
.
M204
DC Bus Voltage Vdc 1 Displays the voltage of the
DC
bus in the main circuit.
M205
Output Power
K
W 0.1 Displays the AC DRIVE output power.
M206
Energy Meter
K
WH
0.1 Displays the energy consumed by the system in kWH.
M207
Energy Meter MWH
1 Displays the energy consumed by the system in MWH.
M208
Heat sink Temperature
C 1 Actual heat sink temperature is displayed.
M209
Torque Current % 0.1 The torque current value is displayed using the motor rated current as
100% .
M210
Excitation Current % 0.1
The excitation current value is displayed using the motor rated current as
100%.
M211
Heat sink Temperature
F 1 Actual heat sink temperature is displayed in degree F.
