Amtech
6-2
6
M212
Energy Saved in kW kWH
1 This parameter displays the saved energy using VFD in kWH.
M213
Energy Saved in MW MWH
1 This parameter displays the saved energy using VFD in MWH.
M214
Hank Count 0.1 Displays the current hank count. The display is limited at a maximum of
6553.5. This is cleared to zero when power is turned off.
M215
Money Saved with VFD 1 This parameter displays the money saved with VFD in energy saving
application. Select appropriate currency (B113) and energy cost (B114).
M216
Money Saved with VFD
X1k
1 This parameter displays the money saved x 1000 with VFD in energy
saving application. Select appropriate currency (B113) and energy cost
(B114).
M217
Encoder Count 1 This parameter displays the Encoder count as per below formula.
Encoder Count = (Encoder Pulses (B109)*Motor Speed (M102)*4*
Speed loop time (B601)) / (60*1000)
M218
ASR O/P Monitor % 0.1 The ASR output is displayed.
M219
ACR O/P Monitor % 0.1 The ACR output is displayed.
M220
Drive Overload % 0.1 This parameter displays drive overload in percentage. Drive overload
fault comes when this value reaches to 100%
M221
Motor Overload % 0.1 This parameter displays motor overload in percentage. Motor overload
fault comes when this value reaches to 100%
GROUP
M301
Total Conductivity Time Hrs 1 The cumulative power on time after product shipment will be counted
and displayed.
M302
Total Run Time Hrs 1 The cumulative AC DRIVE run time after product shipment will be
counted and displayed.
M303
Automatic Tuning display
The progression state of automatic tuning is displayed.
M304
Rated Current A 0.1 This indicates the rated current of the AC DRIVE.
M305
Inverter Type
K
W This indicates the AC DRIVE type.
M306
Control Version Indicates
ROM
version of DSP Control Board PCA-2014A.
M307
PSI-12345678 Status The
ON
/
OFF
state of various programmable sequence input will display.
M308
PSO-1234 R-567 Status The
ON
/
OFF
state of various programmable sequence o/p (selected
function status) will display.
M309
Unit Serial Number It displays the serial number of the unit.
M310
Ship Month It displays the month of unit shipment.
M311
Ship Year It displays the year of unit shipment.
M312
Display Version Indicates
ROM
version of Display Board PCA-2012.
M313
PLC Display 1 1 It displays the signed 16-bit register value from the In-built PLC.
M314
PLC Display 2 1 It displays the signed 16-bit register value from the In-built PLC.
M315
PLC Display 3 1 It displays the signed 16-bit register value from the In-built PLC.
M316
PLC Display 4 1 It displays the signed 16-bit register value from the In-built PLC.
M317
PLC Display 5 1 It displays the signed 16-bit register value from the In-built PLC.
M318
PLC Display 6 1 It displays the signed 16-bit register value from the In-built PLC.
M319
PLC Display 7 1 It displays the signed 16-bit register value from the In-built PLC.
M320
PLC Display 8 1 It displays the signed 16-bit register value from the In-built PLC.
M321
PLC Display 9 1 It displays the signed 16-bit register value from the In-built PLC.
M322
PLC Display 10 1 It displays the signed 16-bit register value from the In-built PLC.
M323
PLC Flag status 0-7 1 It displays the status of the PLC flag.
