Amtech
6-24
6
MODE-D: Auxiliary Drive Parameters
D101
Motor Voltage Vac 415 380 480 1 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting
value depends on the 400V, 500V, 600V or
200V Series model.
575 500 575
690 600 690
230 200 240
D102
Motor Current Amp M304
0.3*
M304
M304 0.1 Insert the rated motor current from the
nameplate.
D103
Motor Frequency Hz 50.0 10.0 600.0 0.1 Set the rated base frequency from the
nameplate.
D104
Motor Speed rpm 1500 1 36000 1 Set the base speed from the motor nameplate.
D105
Motor Output
Rating
kW M305
0.1 1500.0
0.1 The motor’s rated output at the base speed is
set from the nameplate.
D201
Local Set
Frequency
Hz 10.00
0.00 600.00
0.01 This is the frequency set from the operation
panel for auxiliary motor.
D202
Min Frequency Hz 0.10 0.00 600.00
0.01 These two Parameters are used to configure
Minimum and Maximum Frequency of the AC
DRIVE for auxiliary motor.
D203
Max Frequency Hz 50.00
0.10 600.00
0.01
D204
Frequency
Reference Input
1 1 18 1 This is used to select the speed reference for
auxiliary drive.
=1: Local
=3: FSI 4-20mA
=5: FSI 0-20mA
=7: FSI 20-4mA
=9: FSI 20-0mA
=11: Serial
=13: VIN 0-10V
=15: PLC A-O/P 1
=17: PLC A-O/P 3
=2: FSV 0-10V
=4: FSV 0-5V
=6: FSV 10-0V
=8: FSV 5-0V
=10: Static pot
=12: PID Output
=14: IIN 4-20mA
=16: PLC A-O/P 2
=18: PLC A-O/P 4
D205
Line Speed Setting
rpm 1500 0 3000 1 The set value will be displayed as motor speed
in M102 at 50Hz when auxiliary drive is
selected.
D206
Acceleration Time-
1
Sec 10.0 0.1 6000.0
0.1 Time needed for the speed to change from zero
to maximum.
D207
Deceleration Time-
1
Sec 20.0 0.1 6000.0
0.1 Time needed for the speed to change from
maximum to zero.
D301
Manual Torque
Boost
Setting
% 0 0.0 20.0 0.1 When setting manually, set the boost voltage at
0Hz as a percentage in respect to the rated
output voltage. When programmed to zero, it
will be disabled. This is automatically adjusted
by the automatic tuning.
D302
Slip Compensation
Hz 0.0 0.0 5.0 0.1 Set the motor’s rated slip. When setting
manually, set the slip frequency for the motor
rated load in respect to the base frequency. The
output frequency changes according to the
motor rated torque.
D303
DC Brake Start
Frequency
Hz 1.50 0.00 50.00 0.01 It is a frequency at which DC braking is initiated
during stop.
D304
DC Brake Current % 50 15 150 1 Configure amount of current available for the
DC braking when DC braking is used during
stop.
