Amtech Axpert-Eazy Series - Page 72

Amtech
6-26
6
MODE-E: Ring Spinning Frame (RSF) Function Parameters
No.
Parameter
Unit
Def
M
in
Max
Res
Description
WP
GROUP
-
1: RSF / PATTERN RUN PARAMETER SELECTION
E101 RSF/ Pattern Run
Selection
1 1 3 1 =1: Disable
=2: RSF Function
=3: Pattern Run Function
E102 Table-1 Step
Selection
15 1 15 1 Select the number of steps for table-1 for RSF.
E103 Table-2 Step
Selection
15 1 15 1 Select the number of steps for table-2 for RSF.
E104 Table-3 Step
Selection
15 1 15 1 Select the number of steps for table-3 for RSF.
E105 Doff End Alarm
Time
Sec 1 0.1 3000 0.1
Outputs an alarm signal for the set time from
completion of the final step until directly before
stoppage.
E106 Hank Count Gain 1.000 0.001 30.000 0.001 This is hank coun
t calculation gain used to
display the hank count.
E107 Hank Gain
Multiplier
2 1 3 1 =1: X0.1
=2: X1.0
=3: X10
E108 Table Selection 1 1 3 1
Select the required table for RSF / Pattern Run
function.
GROUP
-
2: RSF FREQUENCY
FOR TABLE
-
1
E201 Freq T1-STP1 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-1.
E202 Freq T1-STP2 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-2.
E203 Freq T1-STP3 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-3.
E204 Freq T1-STP4 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-4.
E205 Freq T1-STP5 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-5.
E206 Freq T1-STP6 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-6.
E207 Freq T1-STP7 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-7.
E208 Freq T1-STP8 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-8.
E209 Freq T1-STP9 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-9.
E210 Freq T1-STP10 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-10.
E211 Freq T1-STP11 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-11.
E212 Freq T1-STP12 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-12.
E213 Freq T1-STP13 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-13.
E214 Freq T1-STP14 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-14.
E215 Freq T1-STP15 Hz 5.00 0.01 600 0.01 Set frequency for Table-1, Step-15.
GROUP
-
3: RSF TIME FOR TABLE
-
1
E301 RSF Time T1-
STP1
Sec 10.0 0.1 6000.0 0.1 Set time for Table-1, Step-1 for RSF function.
E302 RSF Time T1-
STP2
Sec 10.0 0.1 6000.0 0.1 Set time for Table-1, Step-2 for RSF function.
E303 RSF Time T1-
STP3
Sec 10.0 0.1 6000.0 0.1 Set time for Table-1, Step-3 for RSF function.
E304 RSF Time T1-
STP4
Sec 10.0 0.1 6000.0 0.1 Set time for Table-1, Step-4 for RSF function.
