Novara 3000 Series ControlPads Instruction Manual
NOVARA CP-3017-TR-US & -NA ControlPads Specifications (Cont.)
Rear Panel Connectors: • Power - One 2-pin Phoenix connector accepting 12V
DC
power
• Serial - Three 3-pin Phoenix connectors for RS-232 connections
Input voltage: V
IH
> +2.7 V
DC
, V
IL
< -2.7 V
DC
Output voltage:
V
OH
> +5.0 V
DC
@ 35 mA max
V
OL
< -5.0 V
DC
@ 35 mA max
• IR - Two 2-pin Phoenix connectors for IR emitters.
Supports generating carriers up to 1.142 MHz. Output only port.
Output voltage:
V
OH
= +3.3 V
DC
+/- 0.3 V
DC
@ 13 mA max
V
OL
= 0 V
DC
+/- 0.3 V
DC
@ 13 mA max
• I/O - One 4-pin Phoenix connector for I/O connections.
Supports sensing contact closure.
Input voltage:
HIGH (no contact closure): V
IH
> 2.5 V
DC
,
LOW (contact closure): V
IL
< 0.8 V
DC
Output voltage:
V
OH
= +3.3 V
DC
+/- 0.3 V
DC
(internal 25k Ohm pull-up resistor),
V
OL
= 0 V
DC
+/- 0.3 V
DC
(200 mA maximum sink current)
• Relay - 1 4-pin Phoenix connector for relay connections capable of switching 24 V
DC
@ 1A
max or 28V
AC
@ 1A max.
• LAN - 1 RJ-45 connector for LAN connectivity.
• Reset Button - 1 pinhole button for factory reset (CP-3017-TR-US only, see FIG. 4 on
page 7 for location of Reset button access).
Supported Baud Rates: Up to 115200
Dimensions (HWD): • CP-3017-TR-US 17-button ControlPads (including knob):
4 11/16" x 8 1/4" x 1 3/4" (11.9 cm x 21.0 cm x 4.5 cm)
Mounts into standard 4-gang US back boxes
• CP-3017-NA 17-button ControlPads (including knob):
CP-3017-NA: 4 11/16" x 6" x 1 3/4" (11.9 cm x 15.2 cm x 4.5 cm)
Mounts into standard 2 gang US, UK, or EU back boxes.
Weight: • CP-3017-TR-US: 0.588 lbs (0.267 kg)
• CP-3017-NA: 0.863 lbs (0.392 kg)
Operating Environment: • Storage temperature range: 14° - 140° F (-10° - 60° C)
• Operating temperature range: 32° - 104° F (0° - 40° C)
• Relative humidity: 5% to 85%, non-condensing
Included Accessories: • Power Supply, 90-240VACIN, 12VOUT, 500mA (24-5791-SA)
• Pre-printed labels (40-0087)
Other AMX Equipment: • CP-RMS, RMS Gateway Module (FG1310-01)
• CC-NIRC, NetLinx IR Emitter (FG10-000-11)
Certifications: FCC Class B, CE, UL, CB Scheme
