Device Configuration Software
58
Novara 3000 Series ControlPads Instruction Manual
2. Right-click the device with undefined fields, and select Rename Device(s). The Rename Device Libraries dialog
opens (FIG. 78).
3. Enter the appropriate information in the undefined fields.
4. Click Rename. The Rename Device Libraries dialog closes, and you can now import the device library.
ASCII to Hex Tool
Use the ASCII to Hex tool to convert ASCII text to a hexadecimal value for device commands.
The following options appear in this window:
FIG. 78 Rename Device Libraries dialog
FIG. 79 ASCII to Hex window
ASCII to Hex Window Options
ASCII Enter ASCII text in this field.
ASCII to Hex button Click this button to convert the ASCII text to Hex.
HEX Displays the Hex equivalent of the ASCII text.
Add Control Characters Select an ASCII control character from the menu to add it to the HEX field. A list of ASCII
control characters appears on the bottom right of the screen.
Copy Hex Click to copy the Hex value into memory.
