Device Configuration Software
38
Novara 3000 Series ControlPads Instruction Manual
To assign a button to a button group:
1. Open the AMX DCS window.
2. Select Button Groups in the Content area. The Button Groups options appear (FIG. 46).
3. Click Assign Button Grouping. The Button Grouping dialog opens (FIG. 47).
4. Use the Button # - Assigned Name options menu to select a ControlPad button.
5. Click the appropriate Group check boxes to assign the selected ControlPad button to a group. Click Check All to
assign the button to all groups.
6. Repeat steps 4 and 5 to assign more ControlPad buttons.
7. Click Save. The dialog closes and the button assignments appear in the Group Assignment Information area in the
AMX DCS window.
Volume Control
The Volume Control area enables you to set the maximum and default volumes for any device connected to the
ControlPad. You cannot add this option to a script. It is a global setting and is set when the ControlPad starts up. Once
you select the volume levels you want, you can program it by clicking the Program Devices button.
The following table lists the Volume Control options:
Perform these steps to set the volume control for a device:
1. In the AMX DCS window, click the plus sign (+) beside Setup in the Content area. A list of setup options appear.
2. Click Vol u m e C o n t rol. The Volume Control options appear (FIG. 48).
FIG. 47 Button Grouping dialog
FIG. 48 Volume Control options
Volume Control Options
Maximum Value Use the slider to set the maximum volume.
Default Value Use the slider to set the default value. The default maximum value is based on the Maximum value you
set. For example, if you set your maximum value to 50, you set the default value to any number
between 0 and 50.
