Device Configuration Software
53
Novara 3000 Series ControlPads Instruction Manual
3. Use the Hours and Minutes menus to indicate the length of the timeout.
4. Click Save to return to the AMX DCS window.
5. Select the timeout from the Timeout menu and create a script. When you program the device, the script will execute
after the specified amount of time elapses without any activity on the ControlPad.
Programming a Device
Click the Program Devices button to program configuration data and scripts to all tagged Novara devices. You can view
the progress of the device update in the Programming Device(s) Monitor dialog (FIG. 74).
The following options appear in this dialog:
FIG. 73 Timeout Properties dialog
FIG. 74 Programming Device(s) Monitor dialog
Programming Device(s) Monitor Dialog Options
Re-Program Unsuccessful This button is enabled if there are any unsuccessful programmed devices. Once clicked, the
system attempts to re-program all unsuccessful devices in the display window.
Display Unsuccessful Opens the Programmed Unsuccessful dialog which displays a list of unsuccessful
programmed devices. The Print button allows you to print the list, and the Close button
closes the window.
Save List Saves the list of successful and unsuccessful items in a text file. A dialog appears to allow
you to give the file a different name before saving it.
Print List Displays the Print Preview page before allowing you to print the page.
Close A warning displays upon closing if there are any unsuccessful devices that have not been
reprogrammed. You have the option to either re-program the devices or continue to exit the
programming devices window
