AMX MST-701

Programming
53
Modero S Series Touch Panels - Configuration & Programming Manual
Button Commands (Cont.)
^BIM Set the input mask for the specified address.
•Syntax:
"'^BIM-<vt addr range>,<input mask>'"
•Variables:
variable text address range = 1 - 4000.
input mask = Refer to the Text Area Input Masking table on page 110 for character types.
•Example:
SEND_COMMAND Panel,"'^BIM-500,AAAAAAAAAA'"
Sets the input mask to ten ’A’ characters, that are required, to either a letter or digit (entry is required).
^BLN Set the number of lines removed equally from the top and bottom of a composite video signal.
The maximum number of lines to remove is 240. A value of 0 will display the incoming video signal unaffected. This
command is used to scale non 4x3 video images into non 4x3 video buttons.
•Syntax:
"'^BLN-<vt addr range>,<button states range>,<number of lines>'"
•Variables:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
number of lines = 0 - 240.
•Example:
SEND_COMMAND Panel,"'^BLN-500,55'"
Equally removes 55 lines from the top and 55 lines from the bottom of the video button.
^BMC Copy attributes of the source button to all the destination buttons. Note that the source is a single button state. Each state
must be copied as a separate command. The <codes> section represents what attributes will be copied. All codes are 2
char pairs that can be separated by comma, space, percent or just ran together.
•Syntax:
"'^BMC-<vt addr range>,<button states range>,<source port>,<source address>,<source state>,
<codes>'"
•Variables:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
• source port = 1 - 100.
• source address = 1 - 4000.
• source state = 1 - 256.
codes:
BM - Picture/Bitmap
BR - Border
CB - Border Color
CF - Fill Color
CT - Text Color
EC - Text effect color
EF - Text effect
FT - Font
IC - Icon
JB - Bitmap alignment
JI - Icon alignment
JT - Text alignment
LN - Lines of video removed
OP - Opacity
SO - Button Sound
TX - Text
VI - Video slot ID
WW - Word wrap on/off
•Example:
SEND_COMMAND Panel,"'^BMC-425,1,1,500,1,BR'"
or
SEND_COMMAND Panel,"'^BMC-425,1,1,500,1,%BR'"
Copies the OFF state border of button with a variable text address of 500 onto the OFF state border of button with a
variable text address of 425.
•Example:
SEND_COMMAND Panel,"'^BMC-150,1,1,315,1,%BR%FT%TX%BM%IC%CF%CT'"
Copies the OFF state border, font, Text, bitmap, icon, fill color and text color of the button with a variable text address of
315 onto the OFF state border, font, Text, bitmap, icon, fill color and text color of the button with a variable text address
of 150.
Note: Use this command if you are using the panel’s default color palette. For custom color palettes, use ^BMF instead.
