AMX MST-701

Programming
89
Modero S Series Touch Panels - Configuration & Programming Manual
NFC Commands
Embedded Codes
The following is a list of G4 compatible embedded codes:
Custom Events for NFC
NFC Read tag
custom event
Reported to the master when the panel reads an NFC Tag.
Custom event type - 700
ID - 1
Flag - 0
Value1 - Tag Type
Value2 - Data Type
Value3 - Length of data in the Text field
Text - NFC Data (of type specified by Value2)
Where Tag Type is:
1 = ISO 15693
2 = ISO 14443A
3 = ISO 14443B
4 = FeliCa (currently not supported)
Data Type is:
0 = custom.text field contains the NFC UID (as a text string)
1 = custom.text contains NFC data (currently not supported)
Embedded Codes
Decimal numbers Hexidecimal values Virtual keystroke Decimal numbers Hexidecimal values Virtual keystroke
8 ($08) Backspace 146 ($92) Delete
13 ($0D) Enter 147 ($93) Home
27 ($1B) ESC 148 ($94) End
128 ($80) CTRL key down 149 ($95) Page Up
129 ($81) ALT key down 150 ($96) Page Down
130 ($82) Shift key down 151 ($97) Scroll Lock
131 ($83) F1 152 ($98) Pause
132 ($84) F2 153 ($99) Break
133 ($85) F3 154 ($9A) Print Screen
134 ($86) F4 155 ($9B) SYSRQ
135 ($87) F5 156 ($9C) Tab
136 ($88) F6 157 ($9D) Windows
137 ($89) F7 158 ($9E) Menu
138 ($8A) F8 159 ($9F) Up Arrow
139 ($8B) F9 160 ($A0) Down Arrow
140 ($8C) F10 161 ($A1) Left Arrow
141 ($8D) F11 162 ($A2) Right Arrow
142 ($8E) F12 192 ($C0) CTRL key up
143 ($8F) Num Lock 193 ($C1) ALT key up
144 ($90) Caps Lock 194 ($C2) Shift key up
145 ($91) Insert
