AMX MST-701

Programming
65
Modero S Series Touch Panels - Configuration & Programming Manual
Button Commands (Cont.)
^JSI Set icon alignment using a numeric keypad layout for those buttons with a defined address range. The alignment of 0 is
followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of the button.
•Syntax:
"'^JSI-<vt addr range>,<button states range>,<new icon alignment>'"
•Variables:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
new icon alignment = Value of 1 - 9 corresponds to the following locations:
•Example:
SEND_COMMAND Panel,"'^JSI-500.504&510.515,1&2,1'"
Sets the Off/On state icon alignment to upper left corner for those buttons with variable text range of 500-504 & 510-515.
?JSI Get the current icon justification.
•Syntax:
"'?JSI-<vt addr range>,<button states range>'"
•Variables:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
custom event type 1006:
Flag - Zero
Value1 - Button state number
Value2 - 1 - 9 justify
Value3 - Zero
Text - Blank
Text length - Zero
Example:
SEND COMMAND Panel,"'?JSI-529,1'"
Gets the button 'OFF state' icon justification information.
The result sent to the Master would be:
ButtonGet Id = 529 Type = 1006
Flag = 0
VALUE1 = 1
VALUE2 = 6
VALUE3 = 0
TEXT =
TEXT LENGTH = 0
^JST Set text alignment using a numeric keypad layout for those buttons with a defined address range. The alignment of 0 is
followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of the button.
•Syntax:
"'^JST-<vt addr range>,<button states range>,<new text alignment>'"
•Variables:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
new text alignment = Value of 1 - 9 corresponds to the following locations:
Example:
SEND_COMMAND Panel,"'^JST-500.504&510.515,1&2,1'"
Sets the text alignment to the upper left corner for those buttons with variable text ranges of 500-504 & 510-515.
1
4
789
6
32
5
0
Zero can be used for an absolu te positio n
1
4
789
6
32
5
0
Zero can be used for an absolu te positio n
